ALHENA

GSI 52K DWT

IMO 9538141

9538141
9538141
9538141
9538141
Vessel’s Name
ALHENA
Vessel’s Classification
Society D.N.V.
Vessel’s P&I Club
U.K. P&I CLUB
Flag
BAHAMAS
Port Of Registry
NASSAU
Owners
NIGHTNGALE SEACARRIERS LTD
Managers
SUPER-ECO TANKERS MANAGEMENT INC.
Call Sign
C6ZP3
IMO Number
9538141
Year Built
2012
Place Built
GUANGZHOU SHIPYARD INT. CO. LTD (GSI)
Type Of Ship
CHEMICAL TANKER
Hull
DOUBLE HULL
Summer Deadweight
52420
Gross Tonnage
30240
Net Tonnage
15650
L.O.A.
183.20 mtrs
L.B.P.
176.00 mtrs
Beam
32,23 mtrs
Depth
18,20 mtrs
Summer Draft
13,02 mtrs
TPC
55,62 MT
Cubic Capacity Incl. Slops 98%
56,353.92m3
Freeboard (S. DRAFT)
5,213 mtrs
Freeboard (SBT)
10.846 mtrs
Parallel Body Length (Light Condition)
82.79 mtrs
Keel To Mast
47.05 mtrs
Crane SWL
1 X 10 Tons
Tanks Coated
YES
Coating
PHENOLIC EPOXY COATING
Type of Cargo Heating System
HEATING COILS
Crude Oil Washing
YES
Inert Gas System
YES
Segregated Ballast Tanks
YES
No of Manifolds
7 x 14”
Type Of Manifolds
CAST STEEL BUTTERFLY
Distance Rail To Manifolds
4,290 Millimetres
Distance Bow To Manifolds
91.96 Metres
Distance Deck To Center Of Manifolds
2.1 mtrs
Manifold Height of sea level upon completion of discharging
12.95 mtrs
5 x
355/254mm
(14/10")
5 x
355/305mm
(14/12")
5 x
355/203mm
(14/8")
12 x
355/406mm
(14/16")
2 x
254/406mm
(10/16")
NUMBER OF CARGO OIL TANKS
6 WING CARGO OIL TANKS & 2 SLOP TANKS + Residual Tank
NUMBER OF SEGREGATIONS
7
CARGO PUMPS
12 CENTRIFUGAL DW 550m3/HR
2 CENTRIFUGAL DW 300m3/HR
CENTRIFUGAL DW70m3/HR
RESIDUAL TANK PUMP
70 Cu. Metres/Hour
MAIN ENGINE
MAN B&W 6S50 MC-C
B.H.P.
12.889 (9.480)
TANK
CAPACITY 100% m3
CAPACITY 98% m3
No 1 CARGO TANK (S)
3541.440
3470.620
No 1 CARGO TANK (P)
3509.770
3439.580
No 2 CARGO TANK (P)
4969.890
4870.500
No 2 CARGO TANK (S)
4975.160
4875.662
No 3 CARGO TANK (P)
4404.420
4316.343
No 3 CARGO TANK (S)
4422.970
4334.525
No 4 CARGO TANK (P)
4398.480
4310.525
No 4 CARGO TANK (S)
4408.340
4320.184
No 5 CARGO TANK (P)
4400.470
4312.477
No 5 CARGO TANK (S)
4415.620
4327.312
No 6 CARGO TANK (P)
4391.930
4304.108
No 6 CARGO TANK (S)
4393.456
4305.600
SLOP TANK (P)
2379.320
2331.747
SLOP TANK (S)
2892.580
2834.736
GRAND TOTAL
57503.846
56353.919
GROUP
CAPACITY 100% m3
GROUP 1
1P&1S
7051.227
GROUP 2
2P&2S
9945.064
GROUP 3
3P&3S
8827.417
GROUP 4
4P&4S
8806.842
GROUP 5
5P&5S
8852.112
GROUP 6
6P&6S
8785.41
TOTAL CAPACITY BALLAST (m3)
21965.08
TOTAL CAPACITY FUEL OIL (m3)
1977.46
TOTAL CAPACITY DIESEL OIL (m3)
237.33
TOTAL CAPACITY FRESH WATER
620.704
TOTAL CAPACITY RESIDUAL (m3)
491.14
